Messier number one - the Crab Nebula wide field
click the image for a 50% pixel view or HERE to return to the index page

 a while back on one of the groups I belong to, I talked about the possibility of imaging M1 with a short focal lngth. Well, it came to
pass this winter, and is quite interesting in its loneliness... there aren't many other dso's in the field, at least none that
I could find visually. This is almost full APS frame, cropped only for stacking error due to a little flex. Just for fun,
I have included a 200% blow up of the area around the nebula, soft, but interesting with lots of colorful stars... hope you enjoy...


 Telescope Explore Scientific David H. Levy Comet Hunter Maksutov-Newtonian 152mm f/4.8 mounted piggyback on Meade LX 200 Classic 12 inch
Camera Canon XT/350d modified with Baader type 1 filter by Hap Griffin
Exposure  40 five-minute sub-exposures at iso 800 for a total of 200 minutes.
 Guiding  PHD Guide from Stark labs with Meade DSI pro I on Meade 12-inch LX 200 Classic at f/3.3 - the stars after stacking are a real testiment to the sky and machine. It doesn't always work this well... {:<))
 Software  Images acquired, calibrated, stacked and color corrected with Nebulosity 2.2.4 from Stark Labs. Further processing in Photoshop CS 3. including GradientXTerminator, Carboni's actions, and SMI enhancement.
some comments

The sky was really quite good for this, and I finally quieted my mirror drift, at least on this series.. I am pleased with the star size and shape, and with the performance of the little Mak-Newt.

I think with care, and some lucky skies, one can make interesting images of tiny objects with the wide field camera.


December 1, 2010 - Julian CA
